描述
5 way cross down leg is a custom aluminum truss connector used when a truss structure needs four horizontal directions plus one downward leg connection from the same node. It is commonly used in stage roof frames, lighting grids, exhibition booth structures, entrance frames, tower supports, and temporary event structures where a cross connection also needs a vertical support direction.
ENO Stage can customize the 5 way cross down leg according to your truss size, connection method, tube orientation, down leg direction, hole position, surface finish, and matching accessories. For custom truss connector projects, we recommend confirming the full structure drawing before production so the cross direction and down leg connection match the complete truss system.
Quick project reference:
- Used for truss layouts that need four horizontal cross directions and one downward support direction.
- Suitable for stage roof nodes, lighting grid intersections, exhibition booth frames, entrance structures, and event support towers.
- Can be matched with square aluminum truss, box truss, bolt truss, spigot truss, or compatible custom truss systems.
- Truss size, tube diameter, wall thickness, hole position, finish, and accessory set can be customized according to drawings.
- Works with pins, clips, bolts, clamps, bases, sleeve blocks, columns, and other matching truss accessories.
Send us your truss size, connection type, required cross and down leg direction, photos, quantity, finish requirement, and project drawing. We can help check whether this 5 way cross down leg can match your existing truss system or new structure design.
Custom 5 Way Cross Connector With Down Leg
This connector helps create a stronger and cleaner truss node where a horizontal cross frame needs to connect with a vertical support or down leg. It is useful for roof support points, lighting grid nodes, booth frames, entrance structures, and rental truss systems that need accurate multi-direction alignment instead of improvised on-site connection methods.
Product Features
- 5 way cross and down leg layout: designed for truss systems that require four horizontal directions plus one downward support direction.
- Custom matching: made according to the customer’s truss size, tube layout, connection type, down leg direction, and project drawing.
- Event-ready aluminum structure: suitable for stage roofs, lighting grids, exhibition booths, entrance frames, tower nodes, and temporary event structures.
- System compatibility: can be produced for spigot truss, bolt truss, square truss, box truss, or compatible custom truss systems.
- Cleaner assembly: helps keep cross beams and vertical supports aligned during setup, teardown, and repeated rental use.
- Finish options: natural aluminum finish, black finish, or project-specific surface treatment can be discussed before production.
Specification Reference
The following details are for customization reference. Final dimensions should be confirmed according to your existing truss size, connection type, load requirement, down leg direction, and installation environment.
| Product type | 5 way cross down leg / truss cross connector with vertical support direction |
| Common use | Stage roof frame, lighting grid, exhibition frame, event entrance, support tower, custom truss structure |
| Material | Aluminum alloy, commonly 6082-T6 or project-matched material |
| Truss type | Square truss, box truss, spigot truss, bolt truss, or custom truss system |
| Connection direction | Four horizontal cross directions with one downward leg direction, customized according to project layout |
| Connection type | Spigot, bolt, or customized connection according to the matching truss system |
| Surface finish | Natural silver aluminum, black finish, or customized finish |
| Customization | Truss size, tube diameter, wall thickness, connection type, hole position, down leg direction, finish, and accessory set |
Applications
Stage Roof Cross Nodes
Used where roof beams need to meet from several directions while one down leg or vertical support connects below the roof grid.
Lighting Grid Support Points
Suitable for lighting grids that require clean cross-frame alignment and a downward connection for support, rigging, or column layout.
Exhibition Booth Frames
Can support booth frames, LED display truss, hanging signs, entrance structures, and custom display layouts.
Rental Truss Systems
Useful for rental companies that need repeatable custom connector parts for stage roofs, towers, entrances, and temporary event structures.
Product Detail Reference
Related Products
Application Cases
Factory And Loading Videos
FAQ
Can this 5 way cross down leg match my existing truss?
Yes. Please send your truss size, tube diameter, wall thickness, connection type, and photos of the existing truss. We can check whether the connector can be customized to match your system.
Can you customize the down leg direction?
Yes. The cross direction, vertical leg direction, hole position, and tube orientation can be discussed according to your structure drawing and installation requirement.
Can you make black 5 way truss connectors?
Yes. Natural aluminum and black finish are common options. Other finish requirements can be discussed according to the project.
What information should I send for quotation?
Please send the truss size, connection type, required cross and down leg direction, quantity, finish, use environment, and any available layout drawing or reference photo.
Is this product suitable for load-bearing structures?
It can be used in event truss structures, but the final load capacity depends on the full structure design, truss size, connection method, span, installation conditions, and safety requirements. Engineering confirmation is recommended for load-critical projects.
Need Custom 5 Way Cross Down Leg Connectors?
Tell us your truss size, connection type, required cross and down leg direction, finish, quantity, and project drawing. ENO Stage can help you customize a 5 way cross down leg solution for stage roofs, lighting grids, exhibition frames, display booths, and event structures.
