描述
4 way tee piece leg down is a custom aluminum truss connector used when a truss frame needs a tee-style horizontal connection with one downward leg or vertical support direction. It is commonly used in stage roof frames, lighting grids, entrance structures, exhibition booth frames, tower support points, and temporary event truss systems.
ENO Stage can customize the 4 way tee piece leg down according to your truss size, connection method, tube orientation, leg down direction, hole position, surface finish, and matching accessories. For custom truss connector projects, the full structure drawing should be confirmed before production so the tee direction and downward leg connection match the complete truss layout.
Quick project reference:
- Used when a truss structure needs a tee connection with one downward support or leg direction.
- Suitable for stage roof nodes, lighting grid support points, entrance frames, exhibition booths, and tower layouts.
- Can be matched with square aluminum truss, box truss, bolt truss, spigot truss, or compatible custom truss systems.
- Truss size, tube diameter, wall thickness, hole position, finish, and accessory set can be customized according to drawings.
- Works with pins, clips, bolts, clamps, bases, sleeve blocks, vertical columns, and other matching truss accessories.
Send us your truss size, connection type, tee direction, leg down direction, photos, quantity, finish requirement, and project drawing. We can help check whether this 4 way tee piece leg down can match your existing truss system or new event structure design.
Custom 4 Way Tee Connector With Leg Down Direction
This connector helps create a cleaner truss node where a tee frame needs to continue horizontally while also connecting to a lower support, down leg, or vertical column. It is useful for roof support points, booth frames, entrance structures, lighting support grids, and rental truss systems that need repeatable custom connector parts.
Product Features
- Tee piece with leg down layout: designed for truss systems that require a tee connection plus one downward support direction.
- Custom matching: made according to the customer’s truss size, tube layout, connection type, leg down direction, and project drawing.
- Event-ready aluminum structure: suitable for stage roofs, lighting grids, exhibition booths, entrance frames, support towers, and temporary event structures.
- System compatibility: can be produced for spigot truss, bolt truss, square truss, box truss, or compatible custom truss systems.
- Cleaner assembly: helps keep tee beams and vertical supports aligned during setup, teardown, and repeated rental use.
- Finish options: natural aluminum finish, black finish, or project-specific surface treatment can be discussed before production.
Specification Reference
The following details are for customization reference. Final dimensions should be confirmed according to your existing truss size, connection type, load requirement, leg down direction, and installation environment.
| Product type | 4 way tee piece leg down / truss tee connector with downward support direction |
| Common use | Stage roof frame, lighting grid, exhibition frame, event entrance, support tower, custom truss structure |
| Material | Aluminum alloy, commonly 6082-T6 or project-matched material |
| Truss type | Square truss, box truss, spigot truss, bolt truss, or custom truss system |
| Connection direction | Tee direction with one downward leg direction, customized according to project layout |
| Connection type | Spigot, bolt, or customized connection according to the matching truss system |
| Surface finish | Natural silver aluminum, black finish, or customized finish |
| Customization | Truss size, tube diameter, wall thickness, connection type, hole position, leg down direction, finish, and accessory set |
Applications
Stage Roof Tee Nodes
Used where roof beams need a tee connection while a down leg or vertical support connects below the roof frame.
Lighting Grid Leg Supports
Suitable for lighting grids that need horizontal tee alignment with a lower support point for columns, rigging, or frame stability.
Entrance And Booth Frames
Can be used in exhibition booths, brand entrances, LED display frames, and temporary display structures.
Rental Connector Inventory
Practical for rental companies that need repeatable tee connector parts for roof systems, towers, entrances, and event layouts.
Product Detail Reference
Related Products
Application Cases
Factory And Loading Videos
FAQ
Can this 4 way tee piece leg down match my existing truss?
Yes. Please send your truss size, tube diameter, wall thickness, connection type, and photos of the existing truss. We can check whether the connector can be customized to match your system.
Can you customize the leg down direction?
Yes. The tee direction, downward leg direction, hole position, and tube orientation can be discussed according to your structure drawing and installation requirement.
Can you make black tee piece connectors?
Yes. Natural aluminum and black finish are common options. Other finish requirements can be discussed according to the project.
What information should I send for quotation?
Please send the truss size, connection type, required tee and leg down direction, quantity, finish, use environment, and any available layout drawing or reference photo.
Is this product suitable for load-bearing structures?
It can be used in event truss structures, but final load capacity depends on the full structure design, truss size, connection method, span, installation conditions, and safety requirements. Engineering confirmation is recommended for load-critical projects.
Need Custom 4 Way Tee Piece Leg Down Connectors?
Tell us your truss size, connection type, required tee direction, leg down direction, finish, quantity, and project drawing. ENO Stage can help you customize a 4 way tee piece leg down solution for stage roofs, lighting grids, exhibition frames, entrances, and event structures.
